Manufacture:
RoHS Certification: No
Applications: Any digital audio cable using the dual-jacket cable with a outer diameter between 4 and 5 mm in diameter.
| Structure | ||||||
| Ferrule Material | Brass | |||||
| Connector Body Material | Polymer | |||||
| Crimp | N/A | |||||
| Epoxy | Optional | |||||
| Termination/Polishing | Polish or hot plate | |||||
| Number of Fibers | 1 | |||||
| Unit | Value | |||||
| Optical Fiber Size | mm | 1 | ||||
| Jacket Diameter | mm | 5 | ||||
| Approximate Weight | g | |||||
| Performance | Criteria for Acceptance and/or [ Test Conditions ] |
Unit | Value | |||||
| Maximum Rating |
Storage Temperature | No Physical Deterioration [ in a Dry Atmosphere ] |
° C | -40 ~ 70 | ||||
| Operation Temperature | No Deterioration in Optical Properties [ in a Dry Atmosphere ] |
° C | -40 ~ 70 | |||||
| Optical Properties |
Typical Loss | (650 nm Light) [ 25°C 50% RH ] |
dB | 2 | ||||
| Maximum Loss | (650 nm Collimated Light) [ 25°C 50% RH ] |
dB | ||||||
